End tape series

Polyester (PET), polypropylene (PP) film as the base material, coated with special electrolyte resistant acrylic glue;
Thickness 0.01-0.06mm. Good resistance to electrolyte, no fading, no residual glue, resistance to voltage breakdown;
Meet environmental requirements such as ROHS2.0/ halogen.

Product application field:

It is specially used for insulation protection and fixing of pole piece, edge, bottom and termination of aluminum shell, steel shell and soft pack battery cell. In order to facilitate tracking, the film printing number is made into digital tape, or the barcode and two-dimensional code are laser engraved on the rubber surface.

Product technical parameters:

Color: Blue, transparent, yellow, green, yellow, gray

Base material: PET

Thickness: 0.01-0.06mm

Peeling force: 0.5-12N/25mm
